Leutron Vision provides a powerful toolkit for grabber and camera control. The toolkit is common for all the PicPort® frame grabbers and for the PentiCam system. We also support other well-known third party vendors of image processing software by providing comprehensive hardware drivers to our products. Ignore Leutron Vision Video Capture and VfW driver to prevent conflicts with using the HALCON Leutron interface simultaneously. Revision 3.1 (Jun 29, 2007): Bug fix in the internal memory allocation. Revision 3.0 (May 15, 2007): HALCON 8.0 version of the interface (included in HALCON 8.0 DVD). Revision 2.10 (Jun 29, 2006): Bug fix in open.

PicPort®-Color framegrabbers provide digitization of color PAL or NTSC video signal. The digitized studio qsuality image is further conditioned in real time and transfered directly to display and/or memeory. PicPort®-Color framegrabbers provide an inexpensive solution successfully used in many different applications and dedicated systems.
PicPort®-Color is a framegrabber:

- for standard color cameras

- studio quality images

- downscaling, mirroring

- color space conversion

- text & graphic overlay

- PCI, CompactPCI, PMC module

- application specific systems

Architecture

All the PicPort® models are based on similar architecture.

I/O Interface

The PicPort® I/O interface generally comprises video input connectors, synchronization and opto-isolated trigger inputs and outputs. PicPort®-Color can handle 4 CVBS or 3 CVBS and 1 S-video connected sources, one being digitized at a time. Switching among sources is performed via software.

The board contains a female cinch composite video connector, a female S-video connector and a female HDsub44-pin connector. The HDsub44-pin connector handles up to 4 video inputs and includes camera power supply output, TTL level H/V sync output, one opto-coupler in and one opto-coupler out to synchronize user application software with external events. With this multi-feature connector, the user application may be operated using just a single cable.

PicPort®-Color PMC modules are equipped with the 44-pin connector only, however 8 opto-coupler inputs and outputs are available.

Host Bus Interface

To match all different requirements of all vision applications developed for industrial environment, the PicPort® framegrabbers are available in standard PCI bus, CompactPCI model and PMC module versions based on PCI bus revision 2.1. All three models are fully compatible in their features, the only difference is in connector interface.

Digitizers

PicPort®-Color cards feature a high quality digitizer channel and additional circuits for image conditioning.

Pixel Stream Manager

The Pixel Stream Manager is the real heart of every PicPort®. It consists of two data paths (DMA channels) with different features (see the figure). Data path A features the following circuits: High Performance Scaler for fine interpolating, detail-preserving, image scaling down to approx. 40×40 pixels with horizontal plus vertical mirroring, Lock Mask Control for text or graphics overlay on the top of the live image and Pixel Packer and Color Space Converter to perform conversion to a desired color format.

The second data path B contains only the Binary Ratio Scaler.

Both data paths contain FIFO buffers for proper synchronizing the DMA transfers.

On Board Controller (Not shown in the figure)

All boards utilize an on-board controller to guarantee performance of real time critical tasks independent of host processor or operating system.

EEPROM (Not shown in the figure)

Each PicPort® board contains a firmware EEPROM that is updated automatically by driver software ensuring compatibility between hardware and software releases. In addition two bytes of the EEPROM are available to OEM's for use as a Software Dongle.

Image Acqustition & Conditioning

Input Format

PicPort®-Color framegrabbers accept video sources compliant with PAL/CCIR or NTSC/RS170 video standards, as composite CVBS or S-video signal format. Pixel shape in accordance with CCIR601 or square format is possible.

Non-standard cameras can be configured with an easy to use Camera Editor by just selecting one of the many predefined cameras, modifying the parameters and saving for future use.

Digitizer and Image Adjustments

The input image first reaches the Image Digitizer, which consists of two major parts. The first one, an A/D convertor, assures real time conversion of input analog video image to digital YUV image data at sampling rate of up to 20 MHz. The resulting video data stream is of the best studio quality.

In the second part of the Digitizer, you can adjust further digitization parameters via software. Brightness, contrast, hue and saturation of a color image are freely programmable within generous limits.

Downscaling and Mirroring

Image scaling and mirroring are operations performed by the Pixel Stream Manager with a range of functionality dependent on the data path (DMA channel) used. DMA channel A with its High Performance Scaler uses a mathematical interpolation method independently along both x and y axes, resulting in an image free from any significant loss of detail.

Alternatively, when the simpler DMA channel B is used, only vertical mirroring and binary downscaling is available.

Full Color Overlay

By means of a Lock Mask feature, unique to PicPort®, image data flowing through DMA channel A can be overlaid by a 1-bit mask created as a compressed bitmap within Windows in the form of text or graphics.

Color Model Conversion

By utilizing the Pixel Packer and Color Space Converter the data on DMA channel A can be converted to monochrome, RGB or YUV with predefined color and bit depths.

Original formatTarget formatBit use
YUV 4:2:2, CCIR656Y8, packed8-bit luminance
YUV 4:2:2, CCIR656Y2, packed2-bit luminance
YUV 4:2:2, CCIR656Y1, packed1-bit luminance
YUV 4:2:2, CCIR656αRGB, 32-bit8-8-8-8
YUV 4:2:2, CCIR656RGB, 24-bit packed8-8-8
YUV 4:2:2, CCIR656RGB, 16-bit5-6-5
YUV 4:2:2, CCIR656αRGB, 15-bit1-5-5-5
YUV 4:2:2, CCIR656RGαB, 15-bit5-5-1-5
YUV 4:2:2, CCIR656RGB, 8-bit3-3-2
YUV 4:2:2, CCIR656YUV 4:4:4, 24-bit packed8-8-8
YUV 4:2:2, CCIR656YUV 4:2:2, 16-bit packedY1V0Y0U0, 8 bits each
YUV 4:2:2, CCIR656YUV 4:2:2, 8-bit packedY1V0Y0U0, Y 8 bit, U, V 4 bits each
YUV 4:2:2, CCIR656YUV 4:1:1, 16-bit
YUV 4:2:2, CCIR656YUV 4:2:0, MPEG
YUV 4:2:2, CCIR656YUV-9, Indeo

Data Transfer

Drivers Leutron Vision

The digitized and conditioned data is transferred using two independent DMA channels directly to the CPU and/or video memory without on board intermediate storage and with minimal CPU intervention. The board acts as a PCI bus master allowing transfers at peak rates of up to 132 MB/s i.e. real time transfer for all acquisition modes.

The two independent DMA channels provide many modes of operation including simultaneous transfer of image data from a single image source to main memory for processing and to video memory for display.

Applications

Vision

With an unparalleled price/performance ratio the PicPort®-Color framegrabbers are well suited for wide range of applications from many different areas including:

- industrial image processing

- vision systems

- security industry

- documentation

- medical applications

- surveillance

Drivers leutron vision provider

- automation technology

- image data bases

Drivers leutron vision goggles

- research and development

- and many more

Utilizing the multimedia drivers available for PicPort®-Color, the framegrabbers can be immediately used with the TWAIN driver to capture images to common office applications (MS Office, CorelDRAW, etc.) as easy as you would do with a scanner. The Video for Windows driver allows recording of video sequences in popular multimedia programs and to save them in the AVI format for example.

The PicPort®-Color boards are also successfully used in application systems, two of which are described in detail below.

LV-2000 Camera with Flash

The set comprises of the LV-2000 color camera, Tru-Flash device, cable and software.

LV-2000 is a color camera (in both PAL and NTSC versions) providing wide range of features including S-video or composite output, auto focus, auto iris, 16× optical power zoom, 128× digital zoom, electronic shutter, white balance, AGC, sharpening etc. All the camera functions may be operated either in automatic or in manual mode and are fully controlled by means of software via the RS-232C interface.

Tru-Flash is an extremely sophisticated flash device fully synchronized with the camera output signal to flash twice, once for each field in the interlaced image frame.

The set comes complete with an all-purpose cable connecting the flash with the camera and a PicPort®-Color framegrabber.

The system can be easily incorporated into other applications simply by including all or part of the sample source code provided to assist the programmer.

QuadriScreen

QuadriScreen is a digital video monitoring system offering a flicker-free, non-interlaced display of four or more video sources on a single high-resolution monitor with unequaled high image quality.

The default configuration consists of a standard PC computer equipped with four PicPort®-Color boards. All the PC components are selected carefully to optimize the price/performance ratio of the system.

The QuadriScreen application is supplied pre-installed on the PC and is ready to run.

QuadriScreen may be used with any video camera accepted by the PicPort®-Color boards. It can be also used with an arbitrary PC monitor, however a 1600×1200 resolution is recommended. The combination of full size, full speed, non-interlaced display with a high monitor refresh rate assures an ergonomic and non-tiring operation.

The most important features of the QuadriScreen system are:

- our live video color images in full resolution and full frame rate on a single monitor

- independent freezing/unfreezing the images

- independent brightness, contrast, hue, and saturation adjustment

- simple one-click operation to save the image

- easy usage, most operations require just a single click

- robust application design

- other configurations are available on request for quantity OEMs (e.g. more than 4 cameras, movement detection,

text and graphic insertion etc.)

QuadriScreen has been successfully installed in

Goggles

- police stations

- underground stations

- hospitals

- traffic control systems

- other surveillance/security systems (bank, prison, large buildings, highways, tunnels, airport, etc.)

Software

LV-SDS

Leutron Vision Software Development Suite, LV-SDS, is a software development package (Windows, Linux) that allows full control of all PicPort® products. The suite consists of Daisy - the basic software interface for PicPort® cards, Camera Editor - easy interactive setup of standard and non-standard cameras, DRAL - a library for handling specific time-critical tasks, DirectCapture - higher level library for the simple design of live-video Windows applications, TWAIN Driver and Video for Windows - provide a simple interface between Leutron Vision hardware and other office and image manipulation programs (e.g. MS Office, CorelDRAW, etc.). Further multimedia drivers, like MCI, are available on request.

PicLab32®

Language and hardware independent library containing several groups of powerful image processing functions. It is a robust tool for programming vision and measurement applications in industry, research and scientific areas.

Third party packages

Several well-known third party packages for real-time image processing and analysis are also supported. Please refer to our detailed software brochure for more details.

Demo Software and Sample Code

The software products come complete with a set of demo programs and additional examples with source code as a guide to the programmer in developing particular applications.

Connector Description

I/O connector configurations

Bellow we outline a short description of the connector interface of PicPort®-Color boards. Please check full pin wiring schemes description of all the multiconnectors if necessary.

PicPort®-Color (version 9512.2 and higher)

The board can handle 4 CVBS or 3 CVBS and 1 S-video connected sources, one of which is being digitized at a time. Switching among sources is performed via software.

The board possesses a female cinch composite video connector, a female S-video connector and a female HDsub 44-pin connector (4 video inputs, camera power supply output, TTL level H/V sync output, 1 optocoupler in and 1 optocoupler out to synchronize user application software with external events, COM1 or COM2 flow through, I2C bus signal, RS232 signal inputs). Thanks to this multifeature 44-pin connector, the user application may be operated using just a single cable.

Drivers Leutron Vision Test

PicPort®-Color (version 9512.1)

This older version of PicPort®-Color was equipped with different connector interface. For more information, please check the PicPort® Series, Getting started.

Connector wiring schemes

Different versions of PicPort®-Color boards are provided with different connector interfaces (as described in previous sub-chapter). The pin wiring schemes of all the connectors are described below.

Note: You can identify the version number of your PicPort®-Color from label sticked on the back side of the board.

PicPort®-Color for standard PCI bus, version 9512.2 and higher

Pin description table for the 44-pin custom camera connector:

PinSignal
14CVBS1 Video Input, Signal
shared with cinch connector 1)
30CVBS2 Video Input, Signal
15Reserved (9512.2, 9513.3)
CVBS3 (9512.4 and higher)
13Analog Ground
29S-Video Input, Y-Signal;
shared with S-video connector
44S-Video Input, C-Signal;
shared with S-video connector
43Analog Ground
28PMD-Red Video output, Signal, 1 Vpp
12PMD-Green Video output, Signal, 1 Vpp
27PMD-Blue Video output, Signal, 1 Vpp
42PMD-CVBS Video Output, Signal, 1 Vpp
11PMD-Hsync Output
41PMD-Vsync Output
26PMD-Analog Ground
23RS232_C1
7RS232_C2
37RS232_C3
22RS232_C4
6RS232_C5
36RS232_C6
21RS232_C7
5RS232_C8
35RS232_C9
20RS232_C10
40GND
8Connector-Identification,
connect this pin to GND inside your cable-connector
9Hsync Output (Active Low)
25Vsync Output (Active Low)
24Reserved (Internally Connected)
39Reserved (Internally Connected)
4I2C - SDA (on request for quantity OEMs)
34I2C - SCL (on request for quantity OEMs)
18TAP 5 V
3TAP 24 V
17Optocoupler Output Emitter
2Optocoupler Output Collector
32Optocoupler Input A1, +24 V Anode
33Optocoupler Input A0, +5 V Anode
19Optocoupler Input K, Cathode
38GND
10+5 V PC Power Supply
1GND
16, 31+12 V , 700 mA max Camera Power Supply (9512.2-3)
950 mA max (9512.4 and higher)
1)Shared means that the same signal is available on both connectors Only one connector can be used at the time

PicPort®-Color for standard PCI bus, version 9512.1

Pin description table for 9-pin custom camera connector:

PinSignal
1CVBS Video Input, Signal
6CVBS Video Input, Ground
3S-Video Input, Y-Signal
2S-Video Input, C-Signal
7S-Video Input, Ground
4Connector-Identification,
connect this pin to ground inside your cable-connector
5+12V/700mA Output, protected
8 & 9Ground

15-pin connector for PicMod-Display:

PinSignal
1Video output, red or chroma, signal, 1 Vpp
6Video output, red or chroma, ground
2Video output, green or CVBS, signal, 1Vpp
7Video output, green or CVBS, ground
3Video output, blue or CVBS, signal, 1 Vpp
8Video output, blue or CVBS, ground
5Video output, Y or CVBS, signal, 1 Vpp
8Video output, Y or CVBS, ground
13Hsync output, TTL-level
14Vsync output, TTL-level
4, 10, 11Ground
9, 12, 15Reserved
Note: This connector is active only if you have an optional PicMod-Display.
Most signal-pins have dual function depending on software settings. In case
of S-video is selected, use pns 5/8 as luminance (Y) and pins 1/6 as chrominance.
This loop-through connector does not work for PicMod-Display, model 9603.1!

PicPort®-Color for CompactPCI bus

Description of 44-pin custom camera connector:

PinSignal
14CVBS1 Video Input, Signal
shared with cinch connector 1)
30CVBS2 Video Input, Signal
15Reserved (9703.0)
CVBS3 (9703.1 and higher)
13Analog Ground
29S-Video Input, Y-Signal;
shared with S-video connector
44S-Video Input, C-Signal;
shared with S-video connector
43Analog Ground
28PMD-Red Video output, Signal, 1 Vpp
12PMD-Green Video output, Signal, 1 Vpp
27PMD-Blue Video output, Signal, 1 Vpp
42PMD-CVBS Video Output, Signal, 1 Vpp
11PMD-Hsync Output
41PMD-Vsync Output
26PMD-Analog Ground
23RS232_C1
7RS232_C2
37RS232_C3
22RS232_C4
6RS232_C5
36RS232_C6
21RS232_C7
5RS232_C8
35RS232_C9
20RS232_C10
40GND
8Connector-Identification,
connect this pin to GND inside your cable-connector
9Hsync Output (Active Low)
25Vsync Output (Active Low)
24Reserved (Internally Connected)
39Reserved (Internally Connected)
4I2C - SDA (on request for quantity OEMs)
34I2C - SCL (on request for quantity OEMs)
18TAP 5 V
3TAP 24 V
17Optocoupler Output Emitter
2Optocoupler Output Collector
32Optocoupler Input A1, +24 V Anode
33Optocoupler Input A0, +5 V Anode
19Optocoupler Input K, Cathode
38GND
10+5 V PC Power Supply
1GND
16, 31+12 V , 950 mA max Camera Power Supply
1)Shared means that the same signal is available on both connectors Only one connector can be used at the time

Drivers Leutron Vision Provider

PicPort®-Color for IndustrialPCI bus

Description of 44-pin custom camera connector:

PinSignal
14CVBS1 Video Input, Signal
shared with cinch connector
30CVBS2 Video Input, Signal
15Reserved
13Analog Ground
29S-Video Input, Y-Signal;
shared with S-video connector
44S-Video Input, C-Signal;
shared with S-video connector
43Analog Ground
28PMD-Red Video output, Signal, 1 Vpp
12PMD-Green Video output, Signal, 1 Vpp
27PMD-Blue Video output, Signal, 1 Vpp
42PMD-CVBS Video Output, Signal, 1 Vpp
11PMD-Hsync Output
41PMD-Vsync Output
26PMD-Analog Ground
23RS232_C1
7RS232_C2
37RS232_C3
22RS232_C4
6RS232_C5
36RS232_C6
21RS232_C7
5RS232_C8
35RS232_C9
20RS232_C10
40GND
8Connector-Identification,
connect this pin to GND inside your cable-connector
9Hsync Output (Active Low)
25Vsync Output (Active Low)
24Reserved (Internally Connected)
39Reserved (Internally Connected)
4I2C - SDA (on request for quantity OEMs)
34I2C - SCL (on request for quantity OEMs)
18TAP 5 V
3TAP 24 V
17Optocoupler Output Emitter
2Optocoupler Output Collector
32Optocoupler Input A1, +24 V Anode
33Optocoupler Input A0, +5 V Anode
19Optocoupler Input K, Cathode
38GND
10+5 V PC Power Supply
1GND
16, 31+12 V , 700 mA max Camera Power Supply
1)Shared means that the same signal is available on both connectors Only one connector can be used at the time

Technical Specifications

BusPCI, CompactPCI, PMC; Revision 2.1
Image inputs3 CVBS + 1 S-video or 4 CVBS
Input formatPAL or NTSC as CVBS or S-video
Image geometry2:1 interlaced;
PAL: 768×576 (square pixels), 720×576 (CCIR601)
NTSC: 720×480 (square pixels), 640×480 (CCIR601)
Pixel geometryCCIR601, square
Digitizers1
Data digitization20 MHz, 16-bit per channel
Image codingYUV 4:2:2, CCIR656
Input LUTn/a
Brightnessprogrammable
Contrastprogrammable
Color hueprogrammable
Color saturationprogrammable
Gainauto
Offsetauto
Downscalinghorizontal 5-tap and vertical 5-tap independently interpolating scaler
Mirroringalong x and/or y axes
Overlayfreely programmable 1-bit lockmask stored in host memory
Color conversionRGB, YUV or monochrome target models with various color depths and data packing
Transfer to hostbus master burst DMA transfer
Transfer ratepeak rate up to 132 MB/s, real time for all acquisition modes
Synchronization, slavefrom CVBS
Line locked PLLUltra Lock®, not applicable for VCR steady image (pause mode)
Plugs for videocinch, S-video, HDsub 44-pin, all female
Trigger in/outopto-isolated input/ output
Camera power out12 V, up to 900 mA, protected
Power requirements5V/750mA (when a camera is powered from the board, the power consumption is increased appropriately)
Operating temperature0-50 °C

Complementary and Related Products

Supporting software

Comprehensive set of software tools consisting of video capture libraries and image processing libraries for Windows NT4/95/98/2000 and for Linux. Please check especially the following ones:

Daisy
Video capture library of LV-SDS (Software Development Suite). Object oriented library of functions controlling all features of PicPort® boards.
Camera editor
An easy-to-use application enabling user to connect one of many predefined video sources or specify another, even nonstandard one.
Real-time Image Sequencer
Allows acquiring image sequences to the CPU memory.

Cameras for use with PicPort®-Color

Leutron Vision offers wide range of industrial CCD cameras. The best suited for work with PicPort®-Color are:

LV-2000/2000CE
Color auto focus camera with 16× zoom and external RS-232C control.
SONY XC-003/003P
Color high resolution 3-chip CCD camera, cosite sampling, asynchronous shutter.
SONY XC-711/711P
Color high resolution 1-chip CCD camera, RGB primary color stripe filter, electronic shutter.
SONY XC-999/999P
Color miniature cigar-type color CCD camera, electronic shutter, CCD iris, auto iris, signal cable can be more than 100 m long.

Correspondent cables

All the necessary cables for connecting a camera to the framegrabber are available.

Related framegrabbers

Picot®-Mono
Framegrabber for monochrome acquisition (CCIR/EIA/nonstandard), with five sync modes and asynchronous acquisition.
PicPort®-Stereo
Fully compatible board with PicPort®-Mono, but with second digitizing channel allowing simultaneous acquisition from two synchronized cameras or from a dual-channel camera.

PentiCam®

PentiCAM is an ultra compact, mobile image processing system for industrial and machine vision, based on standard PC technology and Leutron's PicPort® framegrabbers. PentiCam® is available in a variety of different configurations.

Ordering Imformation

ProductDescription
PicPort®-ColorPCI bus model
PicPort®-Color CPCICompactPCI bus model
PicPort®-Color PMCPMC module
LV-SDSSoftware developer's suite for PicPort® boards
PCI—CPCI adapterTo operate a CompactPCI bus board in a computer with standard PCI bus
Cable HD44m/H12fCamera cable, 3 m, 44-pin HDsub to 2-pin Hirose
